With MBT 3560 we have combined the technology of our standard temperature sensors and the electrical connections from the MBS pressure transmitters with a new developed electronics which has resulted in a compact temperature sensor with a built-in transmitter.The MBT 3560 is designed for use in harsh industrial enviroments where reliable, robust and accurate equipment is required. Available with a wide selection of process and electrical connections. Can be delivered with a 33 mm extension length which makes it possible to measure temperatures up to 200°C without damaging the built-in electronics.
- Ultra compact design
- Acid-resistant stainless steel enclosure (AISI 316L)
- Temperature range -50 °C - +200°C
- Pt 1000 resistance element
- Output signals: 4 - 20 mA or Ratiometric
- Protection tube: ø 8 mm
- Multiple insertion lengths: 50 mm- 250 mm
Characteristic
|
Value
|
| Type |
MBT 3560 |
| Weight |
0.154 Kg |
| Ambient temperature max. [°C] |
85 °C |
| Ambient temperature max. [°F] |
185 °F |
| Connection standard |
ISO 228 |
| Connection type |
G |
| EAN |
5702423196210 |
| Electrical connection |
DIN 43650/PG 9 |
| Enclosure rating |
IP65 |
| Insertion length [in] |
4 in |
| Insertion length [mm] |
100 mm |
| Output signal [mA] |
4 - 20 mA |
| Packing format |
Multi pack |
| Process connection size |
G 1/4 A |
| Protection tube diameter [in] |
0.32 in |
| Protection tube diameter [mm] |
8,0 mm |
| Protection tube material |
AISI 316 Ti |
| Quantity per packing format |
13 pc |
| Sensor Insert |
fixed |
| Supply voltage [V] d.c. |
10,00 - 32,00 V |
| Temperature Range [°C] |
-50 - 120 °C |
| Temperature range [°F] |
-58 - 248 °F |
| Tolerance |
< ± 1% FS |
| Transmitter setting range [°C] |
0 - 100 °C |
| Transmitter type |
Integrated |
| Type designation |
MBT 3560-0000-0100-10-110 |
