Characteristic	Value
Type	KPS43
Weight	1.103 Kg
Ambient temperature [°C]	-25 - 70 °C
Ambient temperature [°F]	-13 - 158 °F
Ambient temperature [°C]	-25 - 70 °C
Ambient temperature range [°F]	-13 - 158 °F
Ammonia application	No
Approval	ABS, BV, C UL US, CCC, CE, DNV, GL, KR, NKK, RINA, RMRS
Burst pressure [bar]	240,0 bar
Contact function	SPDT gold
Contact rating	AC1=10 A, 440 V
Contact rating	AC15=4 A, 440 V
Contact rating	AC3=6 A, 440 V
Contact rating	DC13=12 W, 220 V
Contact rating	for gold 1-30 mA, 5-30 V
Contact rating	LR max. 50 A
Differential [bar]	0,70 - 2,80 bar
Differential [psi]	10,00 - 41,00 psi
EAN	5702423146932
Electrical conn. comments	Metal cable gland
Electrical connection size	Pg 13.5
Enclosure rating	IP67
Identical product	060-410566
Max. test pressure [bar] Pe	180,0 bar
Max. Working Pressure [bar]	120,0 bar
Max. Working Pressure [psig]	1.740 psig
Max. working pressure [bar] Pe	120,0 bar
Max. working pressure [psig] Pe	1.740,0 psig
Packing format	Multi pack
Pressure connection	G 1/4
Pressure connection standard	ISO 228-1
Pressure Male/Female	Female
Pressure range category	Medium pressure
Pressure sensing element	Diaphragm
Product description	Pressure Control
Product Design class	B
Quantity per packing format	8 PC
Regulation range [bar] Pe	1,00 - 10,00 bar
Regulation range [MPa] Pe	0,10 - 1,00 MPa
Regulation range [psig] Pe	14,50 - 145,00 psig
Reset function	AUTO
UL approval file name	E73170

KPS43 Code 060-3120
